| Frequency 50 |
Air flow at 1 speed - extractor by EN 61591 96 m3/h |
Air flow at 2 speed - extractor by EN 61591 127 m3/h |
| Air flow at 3 speed - extractor by EN 61591 163 m3/h |
Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 163 m3/h |
Air Flow at Minimum Speed in Normal Use 96 m3/h |
| Air Flow Rate at Best Efficiency Point - Q BEP 93.4 m3/h |
Air Pressure at Best Efficiency Point P BEP 185 Pa |
Annual energy consumption 39.1 kWh |
| Average Illumination of the Lighting System on the Cooking Surface - E middle 61 lux |
Control panel on one side/two sides One side |
Dimensions of grease filter 300 x 390 mm |
| Display color No |
Distance from light cover to wall 17 mm |
Distance to electric hob 450 mm |
| Distance to gas hob 650 mm |
Electric Power Input at Best Efficiency Point - W BEP 58 W |
Fluid Dynamic Efficiency - FDE hood 8.3 |
| Fluid Dynamic Efficiency Class E |
Grease Filtering Efficiency - GFE hood 67.5 % |
Grease Filtering Efficiency Class D |
| Internal/external motor Internal |
Lighting Efficiency - LE hood 14.5 lux/W |
Lighting Efficiency Class D |
Lighting Efficiency Class D |
Maximum Possible Air Flow 163 m3/h |
Motor unit rated power 85 W |
Motor type/model K-20 025 02 HE |
Net depth 470 mm |
Net height max 85 mm |
Net height min 85 mm |
Net weight 4.2 kg |
Net width 600 mm |
Noise level at 1 speed - extractor by EN 60704-2-13 53 dB |
Noise level at 2 speed - extractor by EN 60704-2-13 58 dB |
Noise level at 3 speed - extractor by EN 60704-2-13 63 dB |
Nominal Power of the Lighting System - W L 4.2 W |
Number of motor units 1 |
Number units of main lighting 1 |
Air exhaust diameter 120 mm |
Type of plug or cable Euro plug |
Power cabel length 220 cm |
Power rating 89 W |
Power Supply Voltage 230V |
Power unit of main lighting 4 W |
Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 63 dB |
Sound Power Emission at Minimum Speed Available in Normal Use 53 dB |
Noise level 63 dB |
Time Increase Factor - f 1.7 |
Type of main lighting LED |
