| Air flow at 1 speed - extractor by EN 61591 260 m3/h |
Air flow at 2 speed - extractor by EN 61591 350 m3/h |
Air flow at 3 speed - extractor by EN 61591 438 m3/h |
| Air flow at 4 speed - extractor by EN 61591 700 m3/h |
Air Flow at Intensive or Boost Setting [If Available] 700 m3/h |
Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 438 m3/h |
| Air Flow at Minimum Speed in Normal Use 260 m3/h |
Air Flow Rate at Best Efficiency Point - Q BEP 434.8 m3/h |
Air Pressure at Best Efficiency Point P BEP 412 Pa |
| Godišnja potrošnja energije 62.9 kWh |
Average Illumination of the Lighting System on the Cooking Surface - E middle 232 lux |
Control panel on one side/two sides One side |
| Country of Origin on Rating Label Made in Poland |
Dimensions of grease filter 320 x 300 |
Display color Red |
| Distance from light cover to wall 5 mm |
Distance to electric hob 450 mm |
Distance to gas hob 650 mm |
| Electric Power Input at Best Efficiency Point - W BEP 166.5 W |
Dinamična efikasnost 29.9 |
Dinamična efikasnost A |
| Grease Filtering Efficiency - GFE hood 71.9 % |
Efikasnost filtriranja masnoće D |
Intensive or Boost Setting Auto-Off time 5 ' |
Internal/external motor Internal |
Osvetljenje 25.2 lux/W |
Klasa efikasnosti osvetljenja B |
Osvetljenje B |
Limitation of Exhaust Air - t limit 9 ' |
Maximum Possible Air Flow 700 m3/h |
Motor unit rated power 260 W |
Motor type/model S-45 |
Net depth 455 mm |
Net height max 1435 mm |
Net height min 1080 mm |
Neto težina 21.46 kg |
Net width 600 mm |
Nivo buke 50 dB |
Nivo buke 55 dB |
Nivo buke 60 dB |
Nivo buke 69 dB |
Nominal Power of the Lighting System - W L 9.2 W |
Number of motor units 1 |
Number units of main lighting 1 |
Prečnik cevi za vazduh 150 mm |
Type of plug or cable Euro plug |
Power Consumption in Standby Mode - Ps 0.25 W |
Power cabel length 170 cm |
Power rating 268.2 W |
Snaga napajanja 230V |
Power unit of main lighting 8.2 W |
Sound Power Emission at Intensive or Boost Setting [if available] 69 dB |
Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 60 dB |
Sound Power Emission at Minimum Speed Available in Normal Use 50 dB |
Nivo buke 60 dB |
Time Increase Factor - f 0.9 |
Type of main lighting LED |
