| Frequency 50 |
Air flow at 1 speed - extractor by EN 61591 101 m3/h |
Air flow at 2 speed - extractor by EN 61591 131 m3/h |
| Air flow at 3 speed - extractor by EN 61591 182 m3/h |
Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 182 m3/h |
Air Flow at Minimum Speed in Normal Use 101 m3/h |
| Air Flow Rate at Best Efficiency Point - Q BEP 102.4 m3/h |
Air Pressure at Best Efficiency Point P BEP 192 Pa |
Godišnja potrošnja energije 42.5 kWh |
| Average Illumination of the Lighting System on the Cooking Surface - E middle 260 lux |
Control panel on one side/two sides One side |
Dimensions of grease filter 505 x 188 x 9 mm |
| Display color No |
Distance from light cover to wall 200 mm |
Distance to electric hob 450 mm |
| Distance to gas hob 650 mm |
Electric Power Input at Best Efficiency Point - W BEP 61.5 W |
Dinamična efikasnost 8.9 |
| Dinamična efikasnost E |
Grease Filtering Efficiency - GFE hood 55.9 % |
Efikasnost filtriranja masnoće E |
| Internal/external motor Internal |
Main lighting colour temperature [K] 3000 |
Osvetljenje 43.3 lux/W |
Klasa efikasnosti osvetljenja A |
Osvetljenje A |
Maximum Possible Air Flow 182 m3/h |
Motor unit rated power 85 W |
Motor type/model K-20 025 02 HE |
Net depth 290 mm |
Net height max 137 mm |
Net height min 137 mm |
Neto težina 4.43 kg |
Net width 598 mm |
Nivo buke 51 dB |
Nivo buke 59 dB |
Nivo buke 65 dB |
Nominal Power of the Lighting System - W L 6 W |
Number of motor units 1 |
Number units of main lighting 2 |
Prečnik cevi za vazduh 120 mm |
Type of plug or cable Euro plug |
Power cabel length 150 cm |
Power rating 91 W |
Snaga napajanja 230V |
Power unit of main lighting 3 W |
Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 65 dB |
Sound Power Emission at Minimum Speed Available in Normal Use 51 dB |
Nivo buke 65 dB |
Time Increase Factor - f 1.7 |
Type of main lighting LED GU10 |
